Kali PTFE Lining provides reliable Teflon Lined Fittings ideal for high-performance industrial applications handling corrosive and high-temperature chemicals. As a Malaysia company specializing in supplying FEP, PFA and PTFE lined components, we are a reliable partner to come to. Our Teflon Lined Fittings are strong, chemical-proof and display steady performance across multiple demanding uses. Due to their smooth inner lining, compact structure, and good sealing performance, these fittings provide effective handling of fluids efficiently and can be purchased in specialized form to meet system requirements and operational conditions.
Teflon Lined Fittings are fittings that are lined on the inside with PTFE (Teflon), a non-reactive material and having excellent chemical and heat resistance. The lining creates a smooth, non-stick surface that eliminates leaks and along with this, reduces contamination and wear. The fittings have widespread application in the chemical processing industry, food and beverage industry, pharmaceutical industry, and water treatment industry, where safety, purity, and durability are of the highest concern.
Size : 25 NB to 300 NB
Flanges Used : ASTM A 105/IS 2062/SS 304/SS 316
Hydro Test : at 29.8 Kg/cm2
Spark Test : 15 KVA
Outer body : ASTM A 234 Gr WPB SCH-40/SS 304/SS 316
Lining : Teflon
Kali PTFE Lining is a leading supplier of Teflon Lined Pipe Fittings in Malaysia, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
NB | ID | RF | OD | PCD | No.Of Holes x Dia Of Holes | Lining Thickness Standard | Lining Thickness Full Vacuum | Length Max. |
| 15 | 10.80 | 34.90 | 88.9 | 60.3 | 4×15.9 | 3.0 | 3.1 | 3000 |
| 20 | 16.00 | 42.70 | 98.4 | 69.8 | 4X15.9 | 3.0 | 3.1 | 3000 |
| 25 | 20.15 | 50.80 | 108.0 | 79.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 40 | 33.90 | 73.00 | 127.0 | 98.4 | 4X15.9 | 3.2 | 3.5 | 3000 |
| 50 | 45.50 | 92.10 | 152.4 | 120.7 | 4X19 | 3.5 | 4.6 | 3000 |
| 65 | 55.68 | 104.80 | 177.8 | 139.7 | 4×19 | 3.5 | 4.8 | 3000 |
| 80 | 70.90 | 127.00 | 190.5 | 152.4 | 4X19 | 3.5 | 5.0 | 3000 |
| 100 | 94.30 | 157.20 | 228.6 | 190.5 | 8X19 | 4.0 | 5.8 | 3000 |
| 150 | 114.10 | 215.90 | 279.5 | 241.3 | 8X22.2 | 5.0 | 6.8 | 3000 |
| 200 | 195.10 | 269.90 | 342.9 | 298.5 | 8X22.2 | 5.0 | 7.9 | 2000 |
| 250 | 247.40 | 323.90 | 406.4 | 362.0 | 12X25.4 | 5.0 | 8.8 | 2000 |
| 300 | 297.00 | 381.00 | 482.6 | 431.8 | 12X25.4 | 5.0 | 9.0 | **** |
Withstands aggressive acids, alkalis, and solvents without degrading.
Performs reliably in elevated temperature environments up to 260°C.
Ensures tight, secure connections for safe and efficient operation.
Offers durability and reduces maintenance costs in harsh industrial settings.
Yes, they are highly resistant to strong acids, alkalis, and solvents, making them ideal for use in harsh chemical environments.
Yes, Teflon Lined Fittings can generally operate at temperatures up to 260°C, depending on the system’s pressure and process conditions.
They are available in standard sizes ranging from 25mm to 300mm, with custom sizes also offered to meet specific system needs.
Absolutely, the Teflon lining provides a secure, leak-proof seal, reducing the risk of failures and minimizing maintenance.
They are widely used in the chemical, pharmaceutical, and food processing industries where corrosion resistance and clean fluid flow are essential.
We are the leading Manufacturer and Supplier of PTFE Lined Pipe, Fittings, Flanges, Spool and Valves in Malaysia.
