Kali PTFE Lining produces high-quality PTFE Lined Reducers for maximum performance in demanding industrial applications. Established in Malaysia, we are a reliable source of PTFE, FEP, and PFA lined products, renowned for their strength and dependability. Our PTFE Lined Reducers are constructed to resist aggressive chemicals and extreme heat, providing stable, long-term performance. With a smooth inner surface and heavy-duty build these reducers provide smooth changes between various pipe sizes. Designed to be made to order according to specific process needs and industry standards, we provide flexible solutions for numerous applications.
A PTFE-lined reducer is a pipe fitting used to join two pipes of various diameters and provide superb chemical resistance with efficient flow. The lining inside is composed of Polytetrafluoroethylene (PTFE), an inert, corrosion-free material, making the product suitable for industries that deal in aggressive chemicals, acids, or high-purity chemicals. PTFE-lined reducers are widely applied in chemical process, pharmaceuticals, food beverage manufacturing, and water treatment. PTFE lining avoids the process fluids coming into contact with anything other than the inert surface minimizing contamination and prolonging equipment life. There are two general types of PTFE-lined reducers: concentric in which centerlines coincide, and eccentric, in which centerlines do not, each engineered for particular flow applications.
Size : 25 NB to 300 NB
Outer body : ASTM A 395 Gr 60-40-18
Flange Connection : ANSI B 16.5
Face to Face : ANSI B 16.10
Spark Test : 15 KVA
Hydro Test : at 29.8 kg/cm2
FEP- Max Temp : 180° C
PP Max Temp : 100° C
PFA Max Temp : 200° C
Kali PTFE Lining is a leading supplier of PTFE Lined Reducer in Malaysia, Kuala Lumpur, offering high-quality, corrosion-resistant solutions ideal for chemical, pharmaceutical, and industrial applications.
| NB | L | FLG. | RF | PCD | App. | App. | LINER THK | N x M | WEIGHTS | |
|---|---|---|---|---|---|---|---|---|---|---|
| O / D | O / D | T1 | T1 | Vaccume (T) | Non Vacc (T) | (kg/piece) | ||||
| 1/2″ | —- | 89 | 35.1 | 60.5 | 14.2 | 24.2 | 3.0 | 3.0 | 4 x 1/2″ | 4 |
| 3/4″ | —- | 98 | 42.9 | 69.9 | 15.7 | 27.7 | 3.0 | 3.0 | 4 x 1/2″ | 3.5 |
| 1″ | 89 | 108 | 50.8 | 79.2 | 17.2 | 29.2 | 4.0 | 3.0 | 4 x 1/2″ | 5.5 |
| 1 1/4″ | 95 | 118 | 63.5 | 88.9 | 18.7 | 30.2 | 4.0 | 3.0 | 4 x 1/2″ | 7.7 |
| 1 1/2″ | 102 | 127 | 73.2 | 98.6 | 20.5 | 32.5 | 4.0 | 3.0 | 4 x 1/2″ | 8.7 |
| 2″ | 114 | 152 | 91.9 | 120.7 | 22.1 | 37.1 | 4.0 | 3.0 | 4 x 1/2″ | 14.0 |
| 2 1/2″ | 127 | 178 | 104.6 | 139.7 | 25.4 | 40.4 | 4.0 | 3.0 | 4 x 5/8″ | 20.6 |
| 3″ | 140 | 191 | 127.0 | 152.4 | 27.9 | 42.9 | 4.0 | 3.0 | 4 x 5/8″ | 24.8 |
| 4″ | 165 | 229 | 157.2 | 190.5 | 28.9 | 43.9 | 4.5 | 3.0 | 8 x 5/8″ | 39.1 |
| 5″ | 190 | 254 | 185.7 | 215.9 | 28.9 | 43.9 | 6.0 | 5.0 | 8 x 3/4″ | 68.8 |
| 6″ | 203 | 279 | 215.9 | 241.3 | 30.4 | 45.4 | 6.0 | 5.0 | 8 x 3/4″ | 79.5 |
| 8″ | 229 | 343 | 269.7 | 298.5 | 33.4 | 48.4 | 6.0 | 5.0 | 8 x 3/4″ | 99.0 |
| 10″ | 280 | 406 | 323.9 | 362.0 | 35.7 | 50.7 | 7.5 | 5.0 | 12 x 7/8″ | 160.0 |
| 12″ | 305 | 483 | 381.0 | 431.8 | 37.8 | 52.8 | 7.5 | 5.0 | 12 x 7/8″ | 280.0 |
Withstands harsh acids and solvents.
Prevents fluid leakage at joints.
Suitable for extreme process heat.
Tailored to fit system specifications.
A PTFE/FEP/PFA lined reducer ensures smooth fluid flow, protects against corrosion, and maintains durability in high-temperature, chemical environments.
Yes, Kali PTFE Lining offers customizable configurations to meet specific process and piping requirements.
All offer chemical resistance, but PTFE is widely used for general applications, FEP allows for easier processing, and PFA offers higher temperature resistance and flexibility.
Lined reducers are commonly used in chemical, pharmaceutical, petrochemical, oil & gas, water treatment, and food processing industries.
We offer both concentric (center-aligned) and eccentric (offset) reducers for different flow and installation needs.
